5.3 CONNECTION MANAGEMENT (MENU 5-3) NOT IN VALUES
 For the Call Manager (F5): this menu is not available.
CONNECTION MANAGEMENT
CALL 1
- PHYSICAL SLOT A …..
- PHYSICAL SLOT B …..
- PHYSICAL SLOT C …..
- TONE SILENCE
- COMMAND TYPE disconnect.
CALL 2
- PHYSICAL SLOT A …..
- PHYSICAL SLOT B …..
- PHYSICAL SLOT C …..
- TONE SILENCE
- COMMAND TYPE disconnect.
--------------------------------------------------
Figure 142: Menu 5-3 (Connection management)
This menu is used to set up unilateral, bilateral or 3-party connections between designated
circuits on tones, on demand.
This menu offers the possibility of setting up 2 separate calls and to check the PBX
transmission plan, between TRK -> SET and SET -> TRK (PSTN check).
CALL 1
PHYSICAL SLOT A
Indicate the physical slot of the first equipment for the first call.
PHYSICAL SLOT B
Indicate the physical slot of the second equipment for the first call.
PHYSICAL SLOT C
Indicate the physical slot of the third equipment for the first call.
TONE
SILENCE TONE 330 HZ TONE 440 HZ HIGH TONE 440 HZ LOW
TONE 440 + 330 HZ INTERNAL MUSIC EXTERNAL MUSIC
Select the type of tone (call 1).
