5.4.2 HARDWARE IDENTIFICATION (MENU 5-4-2)
 For the Call Manager (F5): this menu is not available.
IMPORTANT: This menu is only displayed for XL/XS/XC systems (F6).
This menu is used to display the hardware status of a PBX (slots of cards installed in PBX,
card type, item code, serial number, quantity, etc.)
HARDWARE IDENTIFICATION
FROM THE EQUIPMENT ...
----------------------------------------
Figure 148: Hardware identification (F6)
FROM THE EQUIPMENT
Enter the slot from which the hardware identification is made. For a hardware identification
of the entire PBX (including CPU card), leave the field empty and press Enter to validate.
Note: In an XL, the slots are numbered from 100 to 113 (main cabinet), from 200 to 213
(first expansion cabinet) and from 300 to 313 (second expansion cabinet). In an
XS, the slots are numbered from 100 to 102 (main cabinet) and from 200 to 202
(expansion cabinet).
Press Enter to confirm. The following window opens.
HARDWARE IDENTIFICATION
UCT.-UCT1L
CNMHJ4612AA01 NMNMP031001995
LAN 1 1
SYNC 1 1
HDLC 1 1
TMS 3 1
MEVO 1 4
MEMO 1 32768
ITTS 1 24
MEMF 1 16384
LPT 1 1
RAM 1 32768
FLASH 1 32768
SRAM 1 2048
DPRAM 1 256
----------------------------------------
Figure 149: Hardware identification (example of an XL cabinet)
