FOR THE CLASS
Select the name of a class from those available. If you wish to reset the tables for all CAC
classes, simply select " ……." .
CONFIRMATION
NO YES
If you select YES reset of the desired counters is confirmed.
4.7.8.5 CAC SERVERS STATUS (MENU 4-7-8-5)
 For the Call Manager (F5): Menu 4-7-3-5 (CAC servers status)
IMPORTANT: This menu only appears if the PBX is configured in multi-site mode
(menu 3.6 - Parameters management).
CAC SERVERS STATUS
CENTER MAIN SECONDARY
----------------------------------------------
01-CENTRE1 001-SITE1 002-SITE2
02-CENTRE2 001-SITE1 002-SITE2
03-CENTRE3 003-SITE3 004-SITE4
04-CENTRE4 ........ ........
05-CENTRE5 ........ ........
06-CENTRE6 ........ ........
----------------------------------------------
Figure 132 : CAC servers status
This menu is used to display the status of all the CAC servers in a multi-site configuration.
For each center, the site containing the main CAC server and the site containing the
secondary CAC server are displayed.
