Connexity M6504 - Figure 58: Administration Parameters (Continued)

.
PS8149KENAA01 15/09/2004 Page 91
Ce document est la propriété de EADS et ne doit pas être reproduit ou communiqué sans autorisation.
This document is the property of EADS and may not be copied or circulated without authorisation.
OBSERVATION RECORDS
GENERATING OBSERVATION RECORDS
NO YES
YES validates output of a data observation ticket.
ADMINISTRATION PARAMETERS
------- ALARM MANAGEMENT ---------
- GENERATION OF A SERVICE RECORD NO
- MONITOR TEL. EXTENSION YES
- REPORTED TO NUMBER 78669.
- AND ACKNOWLEDGED BY CODE ....
- TO CENTRALIZING SITE YES
- SITE ........
- SITE ........
SNMP MANAGER IP ADDRESS ...............
X25 ADDRESS No 1 ....................
X25 ADDRESS No 2 ....................
----------------------------------------
Figure 58: Administration parameters (continued)
ALARM MANAGEMENT
GENERATION OF A SERVICE TICKET
NO YES
Alarm record output on the printer or PAD is only possible in format 6500.
SUPERVISION ON TEL. EXT.
NO YES
This field is used to monitor alarms on the ATDC or digital set. The digital set must be
declared as a maintenance set in Extension characteristics (menu 1-1-1). Alarm
management must also be authorised in menu 1-7-2.
REPORTED TO NUMBER
Enter in this field the directory number of the local or remote set which is activated on
reception of alarm signal (only the dry loop alarm).
AND ACKNOWLEDGED BY CODE
This is used to program the acknowledgement code indicating reception of an alarm by the
internal or remote set.
