3.3.1 HARDWARE CONFIGURATION (M6501 L/R IP PBX AND M6504/M6540 IP
PBX) (MENU 3-3-1)
3.3.1.1 M6501L/R IP PBX
CONFIG. MANAGEMENT
CLASS SERVICE TYPE V23
TMS BASIC: : TYPE SUBSC.+SUBSC.
: STATUS IN SERVICE
TMS TOCT: : TYPE SUBSC.+SUBSC.
: STATUS IN SERVICE
--------------------------------------------
Figure 32: Hardware configuration (M6501L/R IP PBX)
CLASS SERVICE TYPE
Note: This line is only displayed for a configuration using both set types.
V23 DTMF
CLASS service allows analogue terminals to receive the following information about the
current call: Caller number (if there is no call offering restriction) and date and time of call
(only available in V23 mode). Analogue terminals using the Class service are special
terminals with a display.
V23 Selection for standard European Class sets
DTMF Selection for Danish Class sets
TMS BASIC:
TYPE
• • • • • •
EXTENSION NETWORK 1 NETWORK 2 For OCT4B
This field cannot be modified because the standard TMS is configured as
EXTENSION For OCT4
