STATUS
IN SERVICE OUT OF SERVICE NOT EQUIP.
This state is selected automatically on Total Reset. The system takes account of the TMS
and downloads them.
OUT OF SERVICE Put 1 TMS out of service.
IN SERVICE Used for downloading new TMS software.
TMS TOCT:
TYPE
• • • • • •
EXTENSION NETWORK 1 NETWORK 2 For OCT4
The TMS TOCT is an additional TMS for a TOCT daughter card TMOCT4 (OCT4).
For the configuration, select TMS TOCT: EXTENSION RAM or NETWORK 2.
3.3.1.2 M6504/M6540 IP PBX
Hardware description
The OCI is equipped by default with a TOCH2 card (HJ2723A), with 2 RAM TMSs and one
MOCI card. These 2 TMSs can be downloaded by programming either in EXTENSION
RAM code (DTMF transmitters and receivers) or in NETWORK RAM code (MF SOCOTEL
transmitters and receivers).
On system start up, the 2 TMs are automatically configured EXTENSION RAM. The TMS
configured as EXTENSION RAM can manage:
♦ 1 x 330 Hz tone generator (-8 dBmo)
♦ 2 x 440 Hz tone generators (-11 dBmo)
♦ 1 x 330/440 Hz tone generator
♦ 2 x 330/440 Hz tone detectors
♦ 2 x 4-party conferences
♦ 2 x DTMF transmitters
♦ 2 x DTMF receivers
The TMS configured as NETWORK RAM 2 can manage:
♦ 1 x 330 Hz tone generator (-8 dBmo)
♦ 1 x 440 Hz tone generator (-11 dBmo)
♦ 1 x 330/440 Hz tone detector
♦ 2 x 4-party conferences
♦ 2 MF SOCOTEL transmitters
♦ 2 MF SOCOTEL receivers
♦ 2 x R2 code receivers
♦ 2 x R2 code transmitters
