PBX Type 1st gen. card 2nd gen. card Daughter card
F1: M6501L/R IP PBX VOCT BVF FBVF
F2: M6504/M6540 IP PBX VOCH CCS
Figure 166: Summary of voice cards installed in F1/F2 PBXs
♦ XL/XS/XC
ANNOUNCEMENT MESSAGES ON SVF-BVF
1 SVF-BVF: VIEW ANNOUNCEMENTS
2 SVF-BVF: ANNOUNCEMENT ALLOCATION
3 SVF-BVF: OBSERVE COUNTERS
4 SVF-BVF: RESET COUNTERS
5 SVF-BVF: RECORD ANNOUNCEMENTS
ENTER YOUR CHOICE .
--------------------------------------------------
Figure 167: Menu 5-5-2 (Announcements on XL/XS/XC)
The recorded messages and announcements are integrated in the CPU card:
PBX Type CPU card Daughter card
XL (F6) UCT-L 2 FMEVO
XS (F6) UCT-S 1 FMEVO
XC (F6) UCT-C
Figure 168: Summary of voice cards installed in F6 PBXs
