3.4.2 M6501L/R IP PBX (OCT4), M6504/M6540 IP PBX AND XL/XS/XC
TERMINAL MANAGEMENT
CONSOLE:
- SPEED NO
- DONGLE ON SERIAL PORT YES
- REMOTE OPER. ACCESS, VIRTUAL PAD YES
- COMPACT_FORMAT HANDLING ACCESS VT100 OR PC
- ACCESS MODE RHM VT100
- ACTIVE SERVICE AT INIT.
MODEM:
- REMOTE OPER. ACCESS, VIRTUAL PAD NO
- ACCESS MODE VT100
PRINTER: V24.9600
- SPEED 40
- FLOW CONTROL WAIT IN SECONDS
---------------------------------------------
TERMINAL MANAGEMENT
VIRTUAL PAD CONNECTION REMAINS NO
---------------------------------------------
Figure 37: Terminal management
This Terminal Management menu is used to define the connection and access mode
between the PBX and its peripherals devices (console, modem, printer).
CONSOLE
THROUGHPUT
V24.300 V24.1200 V24.2400 V24.4800 V24.9600 V24.19200
V24.38400 V24.57600 V24.115200
Select a transmission speed.
Note: By default, the PBX is configured to operate at a transmission speed of
9600 bauds. However, this speed can be changed to synchronise the link with the
terminal connected (see the installation manual).
DONGLE ON SERIAL PORT
NO YES
Select YES to declare a demonstration dongle.
