Connexity M6504 - Figure 59: Administration Parameters (Continued - Alarm Validation on F6)

.
Page 92 15/09/2004 PS8149KENAA01
Ce document est la propriété de EADS et ne doit pas être reproduit ou communiqué sans autorisation.
This document is the property of EADS and may not be copied or circulated without authorisation.
TO CENTRALISING SITE (MULTI SITE OPERATION)
NO YES
Select YES to retransmit alarms to existing remote sites.
SITE
Enter the name(s) of the existing site(s).
SNMP MANAGER IP ADDRESS
Enter the SNMP manager IP address: field of 15 characters in standard format for an IP
address, made up of 4 decimal values and separated by decimal points:
If the IP address is modified, a message is sent to the SNMP requesting information.
SNMP MANAGER CARD SLOT
This indicates in 2 characters (cabinet, card) the location of the PTx card which is
forwarding alarms: this location is only displayed if the information indicated is not 0.
X25 ADDRESS NO. 1 AND NO. 2
Enter the X25 address number of the integrated buffer monitor.
- NUMBER OF ATTEMPTS
Enter the number of authorised attempts.
- DELAY BETWEEN ATTEMPTS
Enter in minutes the delay between two authorised attempts.
ALARM VALIDATION
ADMINISTRATION PARAMETERS
------- ALARM VALIDATION ---------
DRY LOOP ALARM MANAGEMENT 0 NO
- ALARM BEGIN. IF OPEN LOOP YES
DRY LOOP ALARM MANAGEMENT 1 NO
- ALARM BEGIN. IF OPEN LOOP NO
DRY LOOP ALARM MANAGEMENT 2 NO
DRY LOOP ALARM MANAGEMENT 3 NO
RECORD PARKED EXTENSIONS IN LOGBOOK YES
LOGBOOK OUTPUT ON PRINTER NO
----------------------------------------
Figure 59: Administration parameters (continued - alarm validation on F6)
