5.2.1 SERIAL PORT CONFIGURATION TRANSFER
When you validate the serial port as the transfer medium, the following screen is displayed:
Figure 140: Serial port configuration transfer
THROUGHPUT
300 1200 2400 4800 9600 19200 38400 57600 115200
Select the transfer rate (in bauds).
IDENTIFICATION
Enter in this field the identification of the item to be transferred.
CONFIRMATION
NO YES
Select YES to validate the throughput and the item identification.
Note: On restart, the system will reset automatically.
