3.2.5.4 ISDN BOARD SWITCHES STATUS (MENU 3-2-4)
ISDN BOARD SWITCHES STATUS
EQT NO. TYPE DIR NUM. / FX AUTO-SUPPLY
-------------------------------------------------------
0-02-00 S0 300 YES
0-02-01 DECT FBORNE0 YES
0-02-02 T0 FT0-ETSI NO
0-02-03 T0 FT0-ETSI NO
----------------------------------------------------
Figure 29: ISDN board switches status (menu 3-2-4)
This menu indicates the jumper status for each ISDN access of the UCT-S (XS) and UCT-
C (XC) cards.
EQT NO.
Indicates the ISDN access equipment number (cabinet, card, equipment). The S/T0
subscribers on the CPU card (XS and XC) are used in positions 0-02-00 to 0-02-03.
TYPE
Indicates the ISDN subscriber type: T0 (trunk group), S0 (set), DECT (DECT base station).
DIR NUM. / FX
Indicates the associated trunk group (for network, DECT base station) or directory number
(for S0 set).
AUTO-SUPPLY
Indicates whether the access is auto-supplied.
