Connexity M6504 - Figure 26: XC Hardware and Software Configurations - Migration (Menu 3-2-2)

.
PS8149KENAA01 15/09/2004 Page 47
Ce document est la propriété de EADS et ne doit pas être reproduit ou communiqué sans autorisation.
This document is the property of EADS and may not be copied or circulated without authorisation.
♦ XC
MOTHER BOARD MANAGEMENT - MIGRATION
UCT: hardware view software view
XC CONFIGURATION XC
DIG. EN 0-00: IN SERVICE .........
ANAL EN 0-01: IN SERVICE .........
S/T0 EN 0-02: IN SERVICE .........
T0 EN 0-03: DISABLED .........
PTX EN 0-04: IN SERVICE .........
HSCX EN 0-05: IN SERVICE .........
BVF EN 0-06: IN SERVICE ..........
DIGITAL SET: 4 4
ANALOG SET: 4 4
ONLY T0 ACCESS : 0 0
CLASS SERVICE TYPE V23
TMS VC5402 TYPE 5402 : EXTENSION
STAT: IN SERVICE .........
---------------------------------------------------
Figure 26: XC hardware and software configurations – Migration (menu 3-2-2)
UCT: HARDWARE VIEW SOFTWARE VIEW
XC CONFIGURATION
Read-only field. Used to view the device
configuration (one XC-cabinet configuration).
XC XS XXS XL XXL XXXL GX-GLOBAL
Used to view the device software configuration (one
XC-cabinet configuration). You can modify this field in
order to change from one device to another (change
from an XC cabinet to an XS cabinet).
GX-GLOBAL is a software view used for XC =>
XS or XC => XL migration and to display the
position of XC on the CPU card, as well as the
common positions of XS or XL. It is thus possible
to request the transfer of the extensions located
on the XC CPU card to a new location on the XS
or XL. Once the extensions are transferred, we
recommend that you realign the software view
and the hardware view.
