5.6.1.1 SIGNALLING FOR DIGITAL TRK
Figure 193: Signalling for digital TRK
Set each signalling type In service or Out of service.
5.6.1.2 SIGNALLING FOR ANALOGUE TRK
Figure 194: Signalling for analogue TRK
Set each signalling type In service or Out of service.
