4.7.8.3 CENTERS COUNTERS REINITIALIZATION (MENU 4-7-8-3)

 For the Call Manager (F5): Menu 4-7-3-3 (Centers counters reinitialization)

IMPORTANT: This menu only appears if the PBX is configured in multi-site mode

(menu 3.6 - Parameters management).

CENTERS COUNTERS REINITIALIZATION

ACTIVE SERVER: 001-SITE LOC, CCU: 2

COUNTRES:MAXIMUM FLOW REACHED YES

CRITICAL AREA CALLS COUNTERS NO

REFUSED CALL COUNTERS NO

FOR THE CENTRE 02-centre_2

CONFIRMATION YES

-----------------------------------------

Figure 130: Reset the centre counters

This menu is used to reset all or some of the CAC server counters on a centre-by-centre

basis.

Current throughput counters cannot be reset.

ACTIVE SERVER: XXXXX, CCU: ZZ

This line shows the name of the site where the active server and cluster number are

located.

Note: The user resets the counters of the site and cluster indicated in this line and in

this way does not have to change the status of the local tables.

COUNTRES:MAXIMUM FLOW REACHED

NO YES

If you select YES the counters are reset.

CRITICAL AREA CALLS COUNTERS

NO YES

If you select YES the counters are reset.
