4.6.8 STATUS OF TCP TUNNEL CONNECTIONS (MENU 4-6-8)

 For the Call Manager (F5): Menu 4-6-6 (Status of TCP tunnel connections)

STATUS OF CONNECTIONS TCP TUNNEL

NAME DN STATUS LC NO.

----------------------------------------

S04>S20 1101 CONNECT. IN PROGRS

S04>S06 1102 CONNECT. IN PROGRS

S04>S21 0401 CONNECTED 1

----------------------------------------

Figure 100: Status of TCP tunnel connections

This menu is used to display the status of TCP connections. It displays in table format the

name of the connections, their directory number, their status, and the number of logical

channels they have in busy status (if the connection is valid).

STATUS

The Status column displays the following connection statuses:

CONNECT. IN PROGRS Waiting for connection and system requesting

connection.

CONNECT Valid connection.

DISCONNECT Connection failed and disconnected.

4.6.9 STATUS OF INTEGRATED VOICE BOXES (MENU 4-6-9)

 For the Call Manager (F5): this menu is not available.

STATUS OF INTEGRATED VOICE BOXES

1.BVF OVERALL DISPLAY

2 MESSAGES IN A BOX DISPLAY

3 DISPLAY MESSAGES INVOLVED IN AUDIT

4 DISPLAY OF THE GENERAL CHARACTERISTICS

5 BUSY STATISTICS DISPLAY

ENTER YOUR CHOICE .

--------------------------------------------

Figure 101: Status of integrated voice boxes

This menu is used to display the status of integrated voice mailboxes: display of all the

voice mailboxes, listing of the messages in a mailbox, display of hardware characteristics

and message occupation statistics in the flash memory.
