…….. SUPPLY PROCESSOR ANAL. TRK CARD
DIG TRK CARD DATA CARD SUBSCR CARD CONFER CARD
ANAL TRK DEV DIG TRK DEV DATA DEVICE SUBSCR.DEV
MANAGEMENT FALLBACK ACCESS BILLING SUBSCR ACTION
DRY LOOP SUPERVISION CPU_STARTUP INTEGR. BUFFER
BUFFER_BLOCK_0 BUFFER_BLOCK_1 BUFFER_BLOCK_
2
BUFFER_BLOCK_3
BUFFER_BLOCK_4 CAC SERVER
Select an SBL group from the list.
OF ALARM
Select the alarm to be processed in the selected SBL group.
ROUTED TO
RECORD KEY SET CENTRALISING
X25 ADDRESS NO. 1 X25 ADDRESS NO. 2 X25 ADDRESS
Select an output medium.
RECORD
Triggers the transmission of an alarm service record.
KEY
Triggers an LED to light up on a digital set.
SET
Triggers a call to a set (or diverter).
CENTRALISING
Routes the alarm to a centralising site (management centre or
external set).
X25 ADDRESS NO. 1
Transmits the alarm to X25 address number 1.
X25 ADDRESS NO. 2
Transmits the alarm to X25 address number 2.
X25 ADDRESS
Transmits the alarm to both X25 addresses.
Note: The Centralising option is not available in mono-site configuration.
You can configure X25 addresses number 1 and number 2 in menu 4-1
(Administration parameters).
