Slots 2-0 to 3-7 are used on the M6501L IP PBX (double cabinet).
If the equipment interface has LD4 or LT2 cards, these must be put in service using this
menu. The LT2 card is fitted for T2 or S2 (PRI).
The LS2 or LT2 card can only be installed in slot 04 or 05 (and 00 and 01 for 4 T2). You
can therefore use the LS2 card in two ways:
♦ ISDN:T2 Signalling - (telephone mode)
♦ QSIG signalling - (multi-site links)
Example:
You can use an LS2 card for ISDN:T2 in slot 5 and another LS2 card for QSIG
signalling in slot 04.
CAUTION: An LT2 or LS2 card placed in eq1 requires a TMOCT4 card.
CARD (CABINET NUMBER – SLOT NUMBER): TYPE
• • • • • • • • Use the terminal space bar to select a card type.
4 AB. ANAL. LA4 card for 4 analogue extensions.
4 AB. BOTHWAY LM4 card for 4 mixed extensions.
4 AB. COMMON LN4 card for 4 digital extensions.
8 AB. ANAL. LA8 card for 8 analogue extensions.
8 AB. BOTHWAY LM8 card for 8 mixed extensions.
8 AB. COMMON LN8 card for 8 digital extensions.
2 ANAL TK LR1 card with 2 analogue trunk line equipment interfaces.
4 ANAL TK LR4 card with 4 analogue trunk line equipment interfaces.
ISDN 2S0 LS1 card, 2 S0 equipment interfaces configuration.
ISDN T0-S0 LS1 card, 1 T0 + 1 S0 equipment interface configuration.
ISDN 2T0 LS1 card, 2 T0 equipment interfaces configuration.
LD4 T0/S0 card for 2- or 4-channel radio base stations.
TIE LINE IA1/LI1 card for 2- or 4-wire tie-line equipment interfaces.
CA1 Card for 4 V24 asynchronous links.
CS1 Card for 2 X25 asynchronous links.
CP1 Packet circuit coupler card with two equipment interfaces.
LB4 Card with 4 CT2 radio base station equipment interfaces.
LS2 LS2 card with ISDN T2 (PRI) and QSIG signalling.
LT2 Card fitted for S2, T2 (PRI), PCM or reduced.
CC1 Card with synchronous announcements.
BVF Card with IVB and synchronous announcements.
PTx
PTx card which manages links (maximum 16) and carries out
gateway functions (TCP/IP-X25) and tunnelling (X25 over IP).
CAUTION: No PTx card can be enabled unless the network cable is
connected.
