CARD TYPE ON MULTIBUS SIDE
CARDS 0-C1 TO 0-C4: TYPE
• • • • • • • • • Use the terminal space bar to select the CLx card type.
ISDN ADP T2
A
DP card, in T2 configuration with 30 equipment interfaces, each with
its own 64 kb/s B channel + (64 kb/s D channel).
ISDN ADP S2
A
DP card, in S2 configuration with 1 equipment interfaces to which the
thirty 64 kb/s channels + (64 kb/s D channel) are allocated.
ISDN ADQ T2
ADQ card with T2 interface for the public network.
ISDN ADQ S2 ADQ card with S2 interface for a terminal in the system.
ADQ1 T1
ADQ card with 1 T1 interface for the public network.
ADQ2 T1
ADQ card with 2 T1 interface for the public network.
ADQ1 PRI
ADQ card with PRI (Primary Rate Interface).
ADB 4T0-1S0 ADB card, 4 T0 + 1 S0 equipment interfaces configuration.
ADB 4T0-2S0 ADB card, 4 T0 + 2 S0 equipment interfaces configuration.
ADB 5T0 ADB card, 5 T0 equipment interfaces configuration.
ADB 5T0-1S0 ADB card, 5 T0 + 1 S0 equipment interfaces configuration.
ADB 6T0 ADB card, 6 T0 equipment interfaces configuration.
8ACCES LDS
LDSB card with 8 T0/S0 interfaces and 2/4 channel DECT base
stations.
16ACCES LDS
LDSA card with 16 T0/S0 interfaces and 2- or 4 channel DECT base
stations.
CLD CARD CLD card with 16 V24 asynchronous interfaces, V28 electrical mode.
CLM CARD
CLM card with 16 V24 asynchronous interfaces, V28 electrical mode,
(replaces the CLD card).
CLE CARD
CLE card with 4 asynchronous or synchronous line interfaces (HDLC,
X25, SNA type), V11 electrical mode.
CLF CARD
CLF card with 4 serial asynchronous or synchronous line interfaces
(HDLC, X25, SNA type), V10 electrical mode (compatible with V28).
CCP CARD
CCP card: packet circuit coupler with four 64 kb/s synchronous serial
interfaces.
LAT CARD
LAT card with 4 Z interface analogue extensions + 4 I interface digital
extensions + 4 asynchronous line interfaces (electrical mode) and 2 T0
equipment interfaces.
CRI CARD
CRI card which manages links (maximum 16), and carries out gateway
functions (TCP/IP-X25) and tunnelling (X25 over IP).
PVI
PVI card, 1 Ethernet/IP interface and voice over IP gateway (VOIP4-
8/16/32 daughter cards).
CAUTION: No PVI card can be enabled unless the network cable is
connected.
