♦ XC
XC consists of one main cabinet. It cannot be fitted with expansion cards, the subscriber
sockets and the T0/S0 interfaces are built into the CPU card.
Menu 3-2-1 "Common boards management" is, therefore, empty.
CARD (CABINET NUMBER – SLOT NUMBER): TYPE
• • • • • • • • Use the terminal space bar to select a card type.
LN8 8DG.EXT. LN8 card for 8 digital extensions.
LN16X 16DS.SUB. LN16 card for 16 digital extensions.
LM8 8MIXD. EXT. LM8 card for 4 digital extensions and 4 analogue extensions.
LA8 8ANAL.EXT. LA8 card for 8 analogue extensions.
LA16X 16ANAL.SUB LA16X card for 16 analogue extensions.
LR4 4ANAL.TK. LR4 card with 4 analogue trunk line equipment interfaces.
LR4A 4SUPPL.LR LR4 card with 4 analogue trunk line equipment interfaces.
TIE LINE LI1 card for 2- or 4-wire tie-line equipment interfaces.
CA1 Card for 4 V24 asynchronous links.
CS1 Card for 2 X25 asynchronous links.
CP1 Packet circuit coupler card with two equipment interfaces.
LT2 ISDN T2 (24tS) LT2 card in T2 configuration.
REDUCED LT2 LT2 card in reduced configuration (limited to 16TS).
S2 ISDN LT2 LT2 card in S2 configuration.
PRI ISDN LT2 (24 ts) LT2 card in PRI ISDN configuration
PCM LT2 (32it) LT2 card in PCM configuration
T1 PCM LT2 LT2 card in T1 PCM configuration
LD4 LD4 card for T0/S0 access, 2- or 4-channel radio base stations.
00 CHANNEL PTx
PTx card which performs gateway (TCP/IP-X25) and tunnelling (X25
tun. over IP) functions.
CAUTION: No PTx card can be enabled unless the network cable is
connected.
08 CHANNEL PTx
PTx card which performs gateway (TCP/IP-X25), tunnelling (X25
tun. over IP) and 8 voice over IP circuit management functions.
CAUTION: No PTx card can be enabled unless the network cable is
connected.
