150
9-6. HYDRAULIC CYLINDER ASSY
REASSEMBLING
*Reassemble the hydraulic cylinder assy with
reverse procedure of disassembling.
(1) HYDRAULIC CYLINDER ASSY
REASSEMBLING
*Reassemble hydraulic cylinder assy with
reverse procedure of disassembling. Use
following values for reassembling as
adjustment and service standard.
1. Packing case tightening torque ; [72.33lbf•ft]
(Apply the threebond #1901 to thread.)
In case of removing the hose, take the
following procedure for air removal
1) Set the engine speed to [1500~2000 rpm].
2) Turn the steering wheel upto maximum
steering angle and relief the relief valve
for approximate 3 seconds.
3) Turn the steering to left and right by turns
and repeat it 3 to 4 times.
To Next Page
