/ Setting / Set group
Set Grp Change
Cur SetTeam: 01
Exp SetTeam: 01
Total 004 groups
/ Setting / Set group
Download?
set will take effect
after confirmation
DownLoad Cancel
/ Setting / Set group
Download?
Cancel the set and exit
Cancel
DownLoad
/ Setting / Set group
Maintenance possword
000
(a)
(b)
(c) (d)
Figure 7.3-22 Procedure Diagram of Group Setting Change
2- Grp Copy
This device has four setting groups and user can easily copy one group settings and save this
same setting in other group. User can access this function through the following path: “Setting >
Set group”. The procedure detail of group setting copy is explaining in below figure 7.3.23.
/ Setting / Set group
Sorc Team: 01
Dest Team: 01
Total 004 groups
/ Setting / Set group
Maintenance possword
000
(a)
(b)
Grp Copy
Copy
Cancel
Figure 7.3-23 Procedure Diagram of Group Setting Copy
