Modify MP protection principle error. Update 67P，
67G，59，59G，81R，25，32R，Voltage Selection，
backup power automatic switch，SEF control syn
setting desc. Update the setting name 67Gi_PolU.
Modify IDMT setting desc. Update the disturbance
number to: 16 latest fault disturbance waves, 16
latest start disturbance waves and 4 manual
disturbance waves. Update the 50BF_Retr_Ctl
setting range and description. Update 50BF logic,
including 50BF_Retr_Ctl and 50BF_DZTrBu_Ena
and 50BF_Chk_Mod logic, add 50BF enable logic.
Update 50BF_CBFState logic. Update Control Sync
dead line condition to Uab /Ubc /Uca < (Sync_Vol
/1.732). Update Figure 3.34-7 CB03_Pos_Err
current setting from 0.05In to I_Cur_str. Update
OC_Vol_Blk and OC_Neg_Vol range. Update
Figure 5.2.2-3, both 25SYNC_FORBID_LOOP and
25SYN_Sync_BSFlg are 1 is blocked. Update
Figure3.34-2/3 busbar live and dead voltage logic,
update BPAS1~4 logic and font. Update 50BF logic
diagram font. Update “Manual version and
modification history records” Table Number. Update
Voltage Selection BIErr time delay to 30s. Add 37C,
Block Busbar, Gap protection. Add Transfer REF,
CTS, VTS. Add Faulty Phase Selection (FPS); Add
“Fault type selection” description for OC and EF,
modify the SEL table No. and position. Modify 59
Timer and 81URE Application Scope description
error. Add Metering Analog U/I/P/cos description.
Add MC functions: Binary Input, Binary Output,
Interlocking Logic Output.
Update Mul_Cur description from curve start to
current start in all current protection.
Update BPAS Bus_Loss_Vol condition is not meet
live-voltage.
Update Figure 6.1-3.
Update BPAS Overview: modify under voltage to
live voltage.
Updater the Transformer Module description about
7U8I and 8U7I.
Update OC_VCE setting name;
Update Overview Display Diagram of Software
