D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
103
12.40 net routing protocol_binding delete
<ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
protocol_binding rules configuration mode.
Unsigned integer
2
save
Save Protocol-Binding rules configuration
changes.
3
exit
Save Protocol Binding rules configuration
changes and exit current mode.
4
cancel
Roll back configuration changes.
5
Service
Available Service
service type
6
Local_Gatew ay
local gateway type
OPTION interface type
7
Source_Netw ork
source netw ork type
firew all rule address type
8
Destination_Network
destination netw ork type
firew all rule address type
9
source_address_start
starting IP of the Source Netw ork
IP address AAA.BBB.CCC.DDD w here each
part is in the range 0-255
10
source_address_end
ending IP of the Source user
IP address AAA.BBB.CCC.DDD w here each
part is in the range 0-255
11
destination_address_start
start IP of the Destination user
IP address AAA.BBB.CCC.DDD w here each
part is in the range 0-255
12
destination_address_end
ending IP of the Destiation user
IP address AAA.BBB.CCC.DDD w here each
part is in the range 0-255
12.41 net radvd configure
S.No
Command Name
Description
Type and Description
1
save
Save radvd configuration changes.
2
exit
Save radvd configuration changes and exit
current mode.
3
cancel
Roll back radvd configuration changes.
4
enable
enable the RADVD process here to allow
stateless auto configuration of the IPv6 LAN
network
Boolean choice
5
mode
select N to send router advertisements (RAb s)
to all interfaces else Y
radvd advertizement mode type
6
interval
The time in seconds between sending unsolicited
multicast RAb s. The default is 30 seconds.
PPPOE idle timeout Type.
7
flags
RA Flags
8
flags
managed_enable
Chose Managed to use the administered /stateful
protocol for address auto configuration
Boolean choice
9
flags other_enable
the Other flag is selected the host uses
administered/stateful protocol of other (i.e. non-
address) information auto configuration.
Boolean choice
10
preference
Chose betw een low/medium/high for the
preference associated with this routerb s
RADVD process
radvd preference type
11
mtu
This is used in RAb s to ensure all nodes on
the netw ork use the same MTU value in the cases
w here the LAN MTU is not well know n. The
mtu size

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
