Page #129 background image
Wireless Controller CLI Reference Guide
127
String
5
enable_rule
specify whether to enable or disable the rule
Boolean choice
6
protocol
Specify w hether the port uses the TCP or UDP
protocol
type of protocol to be selected for a
application rules.
7
interface
Specify w hether the port uses the TCP or UDP
protocol
interface type
8
outgoing_start_port
start port number of the outgoing traffic
Port number
9
outgoing_end_port
end port of the outgoing traffic
Port number
10
incoming_start_port
start port number of the incoming traffic
Port number
11
incoming_end_port
end port number of the incoming traffic
Port number
14.4 security application_rules edit <ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
application rules rules configuration mode.
Unsigned integer
2
save
Save application rules configuration changes.
3
exit
Save application rules rules configuration changes and
exit current mode.
4
cancel
Roll back application rules configuration changes.
5
name
Name of the rule
String
6
enable_rule
specify whether to enable or disable the rule
Boolean choice
7
protocol
Specify w hether the port uses the TCP or UDP
protocol
type of protocol to be selected for a
application rules.
8
interface
Specify w hether the port uses the TCP or UDP
protocol
interface type
9
outgoing_start_port
start port number of the outgoing traffic
Port number
10
outgoing_end_port
end port of the outgoing traffic
Port number
11
incoming_start_port
start port number of the incoming traffic
Port number
12
incoming_end_port
end port number of the incoming traffic
Port number
14.5 security application_rules delete
<ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
application rules rules configuration mode.
Unsigned integer
14.6 security firewall custom_service add
S.No
Command
Name
Description
Type and Description
1
save
Save custom services configuration changes.
