D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
56
5
type
Enable/disable remote mgmt over https.
Unsigned integer
6
from_address
Set the starting IP in case of range, and the IP to be
allow ed access in case of granting access to a particular
machine
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
7
end_address
Set the Ending IP in case of range.
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
8
port
Set the port you w ant to use for HTTP.
Unsigned integer
9
Status
Enable/disable remote snmp.
Boolean choice
9.6 system remote_management telnet
configure
S.No
Command Name
Description
Type and Description
1
save
save access Management changes for telnet.
2
exit
Save access Management changes for telnet and exit
current mode.
3
cancel
Roll back Remote Mgmt changes.
4
enable
Enable/disable remote mgmt over telnet.
Boolean choice
5
type
The kind of access you want to allow .
Unsigned integer
6
from_address
Set the starting IP in case of range, and the IP to be
allow ed access in case of granting access to a particular
machine
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
7
to_address
Set the Ending IP in case of range.
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
9.7 system snmp trap configure <ltagent_ip>
S.No
Command Name
Description
Type and Description
1
<ltagent_ip>
SNMP trap configuration mode.
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
2
save
Save SNMP trap configuration changes.
3
exit
Save SNMP trap configuration changes and exit current
mode.
4
cancel
Roll back snmp configuration changes.
5
agent
The IP address of the SNMP agent.
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
6
snmp_version
Snmp Version v1/v2/v3
String
7
port
SNMP trap port the trap messages w ill be sent to.
Port number
8
community
The community string to w hich the agent belongs. Most
agents are configured to listen for traps in the Public
community
String

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
