Page #135 background imageLoading...
Page #135 background image
Wireless Controller CLI Reference Guide
133
abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd
w here each part is in the range [0-9A-Fa-f:]
19
destination_add
ress_prefix
Prefix Length of the Destination user
String
14.18 security firewall ipv6 configure
S.N
o
Command
Name
Description
Type and Description
1
save
Save Firew all IPV6 rules configuration changes.
2
exit
Save Firew all IPV6 rules configuration changes
and exit current mode.
3
cancel
Roll back IPV6 rules configuration changes.
4
rule_type
Type of rule to be added
firew all rule type
5
service
.
6
service
service_custom
Name of the custom service for which a rule is to
be added custom name should already be added
into custom service
String
7
service
service_normal
Name of the service for which a rule is to be
added
service type
8
action
Action to be taken by the rule
firew all rule action type
9
schedule
Schedule for which the rule is applicable
String
10
source_address
_type
Type of the source user
firew all rule address type
11
destination_add
ress_type
Type of the destination user
firew all rule address type
12
log
Log Always or Never
firew all rule log enable/disable
13
source_start_ad
dress
IP of the Source user
IP address
abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd
w here each part is in the range [0-9A-Fa-f:]
14
source_end_ad
dress
IP of the Source user
IP address
abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd
w here each part is in the range [0-9A-Fa-f:]
15
source_address
_prefix
prefix length of the Source user
String
16
destination_star
t_address
IP of the Destination user
IP address
abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd
w here each part is in the range [0-9A-Fa-f:]
17
destination_end
_address
IP of the Destiation user
IP address
abcd:abcd:abcd:abcd:abcd:abcd:abcd:abcd
w here each part is in the range [0-9A-Fa-f:]
18
destination_add
ress_prefix
Prefix Length of the Destination user
String
14.19 security firewall ipv6 enable <ltrow_id>
S.No
Command
Name
Description
Type and Description
1
<ltrow_id>
Firew all IPV6 rules configuration mode.
Unsigned integer
