D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
29
configuration for the selected group
56
system group access_control_browser
List of brow sers for which login
policies can be applied
57
system group access_control_browser add
Add a brow ser to Access Control
brow sers list
58
system group access_control_browser delete
<ltrow_id>
Delete a brow ser from Access
Control brow sers list
59
system group access_control_browser show
Displays Access Control browsers list
60
system group access_control_ip
List of ips for w hich login policies can
be applied
61
system group access_control_ip add
Add an ip to Access Control ips list
62
system group access_control_ip delete <ltrow_id>
Delete an ip from Access Control ips
list
63
system group access_control_ip show
Displays Access Control ips list
7.4 UTIL configuration commands
The command util at the CLI prompt would give the description of all the configuration
commands in the branch util , which is as follows:
Sl No
Command Name
Purpose
1
util restore-factory-defaults
Revert to factory default settings.
2
util system_check
system check options
3
util system_check ping <ltip_address>
Ping an Internet Address.
4
util system_check dns_lookup <ltdns>
To retrieve the IP address of a Web,
FTP, Mail or any other Server on
the Internet
5
util system_check traceroute <ltip_address>
display all the routers present
between the destination IP address
and this router
6
util system_check display_IPV4_routingtable
Display IPV4 Routing Table
7
util system_check capturePackets
Allow s you to capture all packets
that pass through the selected
interface
8
util system_check capturePackets start <ltinterface>
Start the packet capture
9
util system_check capturePackets stop
Stop the packet capture
10
util system_check capturePackets download
<ltfileName> <l tipAddr >
Dow nload the packet capture to the
host machine
11
util reboot
Reboot the system.
12
util cat <ltfileName>
Concatenate files and print on the
standard output.
13
util md5sum <ltfileName>
Compute and check MD5 message
digest.
14
util copy <ltfileName1> <ltfileName2>
Copy the Files.
15
util usb_test <ltipAddr> <ltfileName>
To test the USB.
7.5 QoS configuration commands
The command qos at the CLI prompt would give the description of all the configuration
commands in the branch qos , which is as follows:
Sl No
Command Name
Purpose
1
qos lan
Configure qos parameters for lan
2
qos option
Configure qos parameters for option

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
