Page #132 background imageLoading...
Page #132 background image
Wireless Controller CLI Reference Guide
130
14.10 security firewall ipv4
default_outbound_policy
<ltdefault_outbound_policy>
S.No
Command Name
De scription
Type and Description
1
<ltdefault_outbound_policy>
Firew all Settings, Default Outbound Policy
configuration mode.
Boolean choice
14.11 security firewall ipv4 edit <ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
Firew all IPV4 rules configuration mode.
Unsigned integer
2
save
Save Firew all IPV4 rules configuration changes.
3
exit
Save Firew all IPV4 rules configuration changes
and exit current mode.
4
cancel
Roll back IPV4 rules configuration changes.
5
from_zone
Set from Zone security type
firew all rule type
6
from_zone_vlan
Set From Zone VLAN using corresponding VLAN
name
String
7
to_zone
Set to Zone security type
firew all rule type
8
to_zone_vlan
Set To Zone VLAN using corresponding VLAN
name
String
9
service
.
10
service service_custom
Name of the custom service for which a rule is to
be added custom name should already be added
into custom service
String
11
service service_normal
Name of the service for which a rule is to be
added
service type
12
action
Action to be taken by the rule
firew all rule action type
13
schedule
Name of schedule for w hich the rule is applicable
String
14
source_address_type
Type of the source user
firew all rule address type
15
destination_address_type
Type of the destination user
firew all rule address type
16
snat_address_type
Type of the SNAT address
firew all rule snat address type
17
log
Log Always or Never
firew all rule log enable/disable
18
source_address_start
IP of the Source user
IP address AAA.BBB.CCC.DDD w here
each part is in the range 0-255
19
source_address_end
IP of the Source user
IP address AAA.BBB.CCC.DDD w here
each part is in the range 0-255
20
destination_address_start
IP of the Destination user
IP address AAA.BBB.CCC.DDD w here
each part is in the range 0-255
21
destination_address_end
IP of the Destiation user
IP address AAA.BBB.CCC.DDD w here
each part is in the range 0-255
22
qos_priority
Firew all type of service
firew all type of service
