D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
96
2
exit
Save Option port settings and exit current mode.
3
cancel
Roll back Option port settings changes.
4
respond_ping
Disable or Enable ping on Option side
Boolean choice
5
Option1
Option1 port settings
6
Option1 mtu_type
Enter MTU type
mtu type
7
Option1 mtu_size
Enter MTU size for Option1
mtu size
8
Option port_speed
Enter the type of port speed for Option1
Port Speed types
9
Option2
Option2 port settings
10
Option2 mtu_type
Enter MTU type
mtu type
11
Option2 mtu_size
Enter MTU size for Option2
mtu size
12
Option2 port_speed
Enter the type of port speed for Option2
Port Speed types
12.29 net Option configurable_port configure
S.No
Command Name
Description
Type and Description
1
save
Save Configurable Option settings.
2
exit
Save configurable Option settings and exit current mode.
3
cancel
Roll back Configurable Option settings changes.
4
port_name
Select the configurable port type
OPTION interface type
12.30 net Option Option1 ipv6 configure
S.No
Command Name
Description
Type and Description
1
save
Save ipv6 Option1 configuration changes.
2
cancel
Roll back ipv6 Option configuration changes.
3
exit
Save ipv6 Option1 configuration changes and current
mode.
4
isp_type
Set ISP Type
ISP Types.
5
dhcpc
Set DHCPC Configurations
6
dhcpc
stateless_mode_en
able
Set Stateless Mode
stateless mode configuration.
7
dhcpc
prefix_delegation_
enable
Enable prefix delegation
Boolean choice
8
static
set ipv6 address
9
static ip_address
set ipv6 address
IP address
abcd:abcd:abcd:abcd:abcd:abcd:a
bcd:abcd w here each part is in the
range [0-9A-Fa-f:]
10
static prefix
set prefix length
Unsigned integer
11
static
gatew ay_address
Set ipv6 gatew ay address
IP address
abcd:abcd:abcd:abcd:abcd:abcd:a
bcd:abcd w here each part is in the
range [0-9A-Fa-f:]
12
static primary_dns
Set ipv6 primary dns address

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
