D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
128
2
exit
Save custom services configuration changes and exit
current mode.
3
cancel
Roll back custom services configuration changes.
4
name
Name of the service for which a rule is to be added
String
5
protocol
Protocol
type of protocol to be selected for a
custom service.
6
start_port
port number of the Destination user
Port number
7
icmp_type
port number of the Destination user
number in range of 0-40(icmp) or 1-
255(icmpv6)
8
finish_port
Port of the Destiation user
Port number
14.7 security firewall custom_service edit
<ltrow_id>
S.No
Command
Name
Description
Type and Description
1
<ltrow_id>
custom services configuration mode.
Unsigned integer
2
save
Save custom services configuration changes.
3
exit
Save custom services configuration changes and exit
current mode.
4
cancel
Roll back custom services configuration changes.
5
name
Name of the service for which a rule is to be added
String
6
protocol
Protocol
type of protocol to be selected for a
custom service.
7
start_port
port number of the Destination user
Port number
8
icmp_type
port number of the Destination user
number in range of 0-40(icmp) or 1-
255(icmpv6)
9
finish_port
Port of the Destiation user
Port number
14.8 security firewall custom_service delete
<ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
custom services configuration mode.
Unsigned integer
14.9 security firewall ipv4 configure
S.No
Command Name
Description
Type and Description
1
save
Save Firew all IPV4 rules configuration changes.
2
exit
Save Firew all IPV4 rules configuration changes and
exit current mode.
3
cancel
Roll back IPV4 rules configuration changes.
4
from_zone
Set from Zone security type
firew all rule type

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
