D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
48
1
save
Save WLAN Global settings.
2
exit
Save WLAN Global Configuration and exit
current mode.
3
cancel
Roll back WLAN Global settings changes.
4
peer_group_id
Configure the peer sw itch group ID
Unsigned integer
5
client_roam_timeout
Configure client roam timeout
Unsigned integer
6
ad_hoc_client_timeout
Configure entry age for ad hoc netw ork status
Unsigned integer
7
ap_failure_status_timeout
Configure entry age for AP failure status.
Unsigned integer
8
mac_authentication_mode
Configure the MAC Authentication Mode
MAC Authentication mode
9
rf-scan_status_timeout
Configure entry age for RF scan status
Unsigned integer
10
detected_client_status_timeout
Configure entry age for detected clients
status
Unsigned integer
11
tunnel_ip_mtu_size
Configure the Tunnel MTU.
MAC Authentication mode
12
cluster_priority
Configure the Cluster Priority.
Unsigned integer
13
enable_ap_client_QoS
Enable/Disable AP QoS for w lan clients
Boolean choice
8.26 wlan peer_controller configure
S.No
Command Name
Description
Type and Description
1
save
Save peer controller configuration changes.
2
cancel
Roll back peer controller configuration
changes.
3
exit
Save peer controller configuration changes
and current mode.
4
enable_global
Enable/Disable global configuration push to
peer sw itches.
Boolean choice
5
enable_discovery
Enable/Disable discovery configuration push
to peer sw itches.
Boolean choice
6
enable_channel/pow er
Enable/Disable channel and pow er
configuration push to peer sw itches.
Boolean choice
7
enable_ap_database
Enable/Disable AP database configuration
push to peer sw itches.
Boolean choice
8
enable_device_location
Enable/Disable device location configuration
push to peer sw itches.
Boolean choice
9
enable_ap_profile
Enable/Disable AP profile and netw ork
configuration push to peer sw itches.
Boolean choice
10
enable_known_client
Enable/Disable known client configuration
push to peer sw itches.
Boolean choice
11
enable_captive_portal
Enable/Disable Captive Portal configuration
push to peer sw itches.
Boolean choice
12
enable_radius_client
Enable/Disable RADIUS client configuration
push to peer sw itches.
Boolean choice
13
enable_QoS_acl
Enable/Disable QoS ACL configuration push
to peer sw itches.
Boolean choice
14
enable_QoS_diffserv
Enable/Disable QoS DiffServ configuration
push to peer sw itches
Boolean choice
15
enable_wds_group
Enable/Disable w ds group configuration push
to peer sw itches.
Boolean choice

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
