Wireless Controller CLI Reference Guide
40
8.2 wlan ap_management ap_database add
<macaddr>
S.No
Command Name
Description
Type and Description
1
<macaddr>
w lan ap-management ap-database
configuration mode
MAC address AA:BB:CC:DD:EE:FF
w here each part is in the range 00-FF
2
save
Save ap-database configuration changes.
3
cancel
Roll back ap-database configuration
changes.
4
exit
Save ap-databse configuration changes and
current mode.
5
mode
Configure the AP Managed mode
AP mode
6
location
Configure the AP location description.
String
7
password
Configure the AP Authentication Passw ord.
String
8
profileid
Set the AP Profile ID to use for configuration.
AP Profile ID
9
ssid
Configure the stand-alone AP expected SSID
String
10
channel
Configure the stand-alone AP expected
channel
Unsigned integer
11
w ds_mode
Configure the stand-alone AP expected WDS
mode
stand-alone AP expected WDS mode.
12
security_mode
Configure the stand-alone AP expected
security mode
Stand Alone AP Security Mode
13
w ired-mode
Configure the stand-alone AP expected w ired
network mode.
stand-alone AP expected w ired network
mode
14
radio1-sentry
Configure fixed radio channel/pow er settings
15
radio2-802.11b/g/n
Configure fixed radio channel/pow er settings
16
radio1-sentry channel
Configure a fixed channel for the radio
Unsigned integer
17
radio1-sentry power
Configure a fixed transmit pow er for the
radio.
range of power perventage
18
radio2-802.11b/g/n
channel
Configure a fixed channel for the radio.
Unsigned integer
19
radio2-802.11b/g/n
power
Configure a fixed transmit pow er for the
radio.
range of power perventage
8.3 wlan ap_management ap_database edit
<macaddr>
S.No
Command Name
Description
Type and Description
1
<macaddr>
w lan ap-management ap-database
configuration mode
MAC address AA:BB:CC:DD:EE:FF
w here each part is in the range 00-FF
2
save
Save ap-database configuration changes.
3
cancel
Roll back ap-database configuration
changes.
4
exit
Save ap-databse configuration changes and
current mode.
5
mode
Configure the AP Managed mode
AP mode
6
location
Configure the AP location description.
