Page #106 background imageLoading...
Page #106 background image
Wireless Controller CLI Reference Guide
104
default is 1500
12
life_time
The lifetime in seconds of the route. The default is
3600 seconds.
Unsigned integer
12.42 net radvd pool add
S.No
Command
Name
Description
Type and Description
1
save
Save radvd Pool configuration changes.
2
exit
Save radvd Pool configuration changes and exit
current mode.
3
cancel
Roll back radvd Pool configuration changes.
4
prefix_type
Option whether to select the prefix type as 6to4 or
Global/Local/ISATAP
ipv6 prefix type
5
sla_id
The SLA ID (Site-Level Aggregation Identifier) in the
6to4 address prefix is set to the interface ID of the
interface on w hich the advertisements are sent
Unsigned integer
6
prefix_address
It specifies the IPv6 network address
String
7
prefix_length
The prefix length variable is a decimal value that
indicates the number of contiguous, higher order bits
of the address that make up the netw ork portion of
the address
Unsigned integer
8
prefix_life_time
The length of time over w hich the requesting router is
allow ed to use the prefix
Unsigned integer
12.43 net radvd pool edit <ltrow_id>
S.No
Command
Name
Description
Type and Description
1
<ltrow_id>
radvd Pool configuration mode.
Unsigned integer
2
save
Save radvd Pool configuration changes.
3
exit
Save radvd Pool configuration changes and exit
current mode.
4
cancel
Roll back radvd Pool configuration changes.
5
prefix_type
Option whether to select the prefix type as 6to4 or
Global/Local/ISATAP
ipv6 prefix type
6
sla_id
The SLA ID (Site-Level Aggregation Identifier) in the
6to4 address prefix is set to the interface ID of the
interface on w hich the advertisements are sent
Unsigned integer
7
prefix_address
It specifies the IPv6 network address
String
8
prefix_length
The prefix length variable is a decimal value that
indicates the number of contiguous, higher order bits
of the address that make up the netw ork portion of
the address
Unsigned integer
9
prefix_life_time
The length of time over w hich the requesting router is
allow ed to use the prefix
Unsigned integer
12.44 net radvd pool delete <ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
radvd pool configuration mode.
Unsigned integer
