D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
50
5
configured_auth_rate
Enable or Disable the configured rate of 802.11 Auth
Requests test.
Boolean choice
6
configured_deauth_rate
Enable or Disable the configured rate of 802.11 Deauth
Requests test.:
Boolean choice
7
configured_probe_rate
Enable or Disable the configured rate of 802.11 Probe
Requests test.
Boolean choice
8
known_client_database
Enable or Disable the client present in Know n DB Test
Boolean choice
9
max_auth_failure
Enable or Disable the Maximum number of Authentication
Failures test.
Boolean choice
10
oui_database
Enable or Disable the client present in OUI DB Test.
Boolean choice
11
threat_mitigation
Enable or Disable Client Threat Mitigation.
Boolean choice
12
known_db_location
Configure the Known Client database location.
w ireless ap
validation type
13
known_db_radius_server_
name
Configure the Known Client database server name
String
14
rogue_det_trap_interval
Set the Rogue Detection Trap Interval
Unsigned integer
15
threshold_interval_deauth
Configure the De-Authentication Requests Threshold Interval.
Unsigned integer
16
threshold_value_deauth
Configure the De-Authentication Requests Threshold Value
Unsigned integer
17
threshold_value_auth
Configure the Authentication Requests Threshold Value.
Unsigned integer
18
threshold_interval_probe
Configure the Probe Requests Threshold Value.
Unsigned integer
19
threshold_value_probe
Configure the Probe Requests Threshold Value
Unsigned integer
20
threshold_auth_failure
Configure the Authentication Failures Threshold Value.
Unsigned integer
8.30 wlan wlan_global_setting ap_validation
configure
S.No
Command Name
Description
Type and
Description
1
save
Save ap validation configuration changes.
2
cancel
Roll back ap validation configuration changes.
3
exit
Save ap validation configuration changes and current mode.
4
validation
Use local AP database or configured RADIUS server to
validate discovered APs
w ireless ap
validation
type
5
authentication
Enable/Disable AP authentication mode.
Boolean
choice
8.31 wlan wlan_global_setting radius_server
configure
S.No
Command Name
Description
Type and
Description
1
save
Save radius server configuration changes.
2
cancel
Roll back radius server configuration changes.

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
