D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
87
115
japanese_pppoe
primary_profile static_ip
Valid IP Address
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
116
japanese_pppoe
primary_profile
subnet_mask
Valid subnet mask
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
117
japanese_pppoe
secondary_profile
configure the secondary pppoe profile
118
japanese_pppoe
secondary_profile
username
Enter the username to authenticate
String
119
japanese_pppoe
secondary_profile
password
Enter the passw ord to authenticate
String
120
japanese_pppoe
secondary_profile service
Enter the passw ord to authenticate
String
121
japanese_pppoe
secondary_profile
authOpt
Enter the Auth Option to authenticate
PPPOE Authentication Types.
122
japanese_pppoe
secondary_profile
connectivity_type
Enter the connectivity type
ISP Connectivity Types.
123
japanese_pppoe
secondary_profile idletime
Enter the idle time
idle timeout value type.
124
japanese_pppoe
secondary_profile
get_dns_from_isp
Enter Yes to get dns dynamically from ISP if you
have not been assigned any static IP address. The
ISP w ill automatically assign an DNS address to the
router using PPPOE network protocol. Otherwise
Enter No and give valid static dns addresses
Boolean choice
125
japanese_pppoe
secondary_profile
primary_dns
Valid primary DNS Server IP Address
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
126
japanese_pppoe
secondary_profile
secondary_dns
Valid secondary DNS Server IP Address
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
127
japanese_pppoe
secondary_profile
get_ip_from_isp
Enter Yes to get IP dynamically from ISP if you have
not been assigned any static IP address. The ISP w ill
automatically assign an IP address to the router
using PPPOE network protocol. Otherwise Enter No
and give valid static IP address
Boolean choice
128
japanese_pppoe
secondary_profile
static_ip
Valid IP Address
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
129
japanese_pppoe
secondary_profile
subnet_mask
Valid subnet mask
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
130
japanese_pppoe
mac_type
Select the Mac Address Source
Types of mac address source
131
japanese_pppoe
mac_address
enter Valid MAC address
MAC address
AA:BB:CC:DD:EE:FF where each
part is in the range 00-FF
12.26 net Option Option2 ipv4 configure
S.No
Command Name
Description
Type and Description

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
