Wireless Controller CLI Reference Guide
117
13.22 vpn sslvpn route delete <ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
Delete sslvpn client route
Unsigned integer
13.23 vpn sslvpn users domains add
S.No
Command Name
Description
Type and Description
1
save
Save users domains configuration
changes.
2
exit
Save users domains configuration changes
and exit current mode.
3
cancel
Roll back users domains configuration
changes.
4
domain_name
Specify the domain name
String
5
authentication_type
Specify the authentication type
Users domain authentication type
6
portal
Select the portal
String
7
authentication_server
1
Specify the authentication server
IP address AAA.BBB.CCC.DDD w here each part
is in the range 0-255
8
authentication_server
2
Specify the authentication server
IP address AAA.BBB.CCC.DDD w here each part
is in the range 0-255
9
authentication_server
3
Specify the authentication server
IP address AAA.BBB.CCC.DDD w here each part
is in the range 0-255
10
timeout
Specify the timeout value
Unsigned integer
11
retries
Specify the max retries
Unsigned integer
12
authentication_secret
Enter the secret key
String
13
authentication_secret
2
Enter the secret key
String
14
w orkgroup
Specify the w ork group
String
15
second_workgroup
Specify the w ork group
String
16
ldap_base_dn
Specify the ldap base domain name
String
17
second_ldap_base_d
n
Specify the ldap base domain name
String
18
active_directory_dom
ain
Specify the active directory domain
String
19
second_active_direct
ory_domain
Specify the active directory domain
String
13.24 vpn sslvpn users domains edit
<ltrow_id>
S.No
Command Name
Description
Type and Description
1
<ltrow_id>
Users domain configuration mode
Unsigned integer
