D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
67
Chapter 11. Configure commands
QOS
11.1 qos lan status
S.No
Command Name
Description
1
lan status
display status of lan qos
2
lan enable
enable qos on lan
3
lan disable
disable qos on lan
4
lan trustmode
configure trustmode configuration in the sw itch
5
lan trustmode status
show the trust mode configuration on the sw itch
6
lan trustmode cos
configure cos based qos on a sw itch port
7
lan trustmode dscp
configure dscp based qos on a sw itch port
8
lan cos-map
configures the cos-map for the switch port
9
lan trustmode cos enable
configures trustmode cos based qos on lan
10
lan trustmode dscp enable
configures trustmode as dscp qos on lan
11
lan cos-map show
show the cos-map for the for LAN
12
lan cos-map configure
configure cos map for qos
13
lan dscp-map
configures the dscp-map for switch
14
lan dscp-map show
display dscp priority mappin on sw itch
15
lan dscp-map configure
configure dscp map for qos
16
lan cos-to-dscp-remarking enable
enables cos-to-dscp remarking
17
lan cos-to-dscp-remarking disable
disables cos-to-dscp remarking
18
lan queue
queue sheduling and management configuration
19
lan queue management
lan queue managenet configuation
20
lan queue management show
queue management configuation show
21
lan queue scheduling-algo
configure queue-scheduling-algo
22
lan queue scheduling-algo set
set the queue scheduling algorithm in the LAN sw itch
23
lan queue scheduling-algo show
show the queue scheduling algo in the LAN sw itch
24
lan cos-to-dscp-remarking configure
disables cos-to-dscp remarking
25
option status
display status of option qos
26
option enable
enable qos on option
27
option disable
disable qos on option interface
28
option bandw idth
set the bandwidth for option interface
29
option bandw idth set
set the bandwidth for option interface
30
option bandw idth show
show the bandwidth for option interface
31
option bw -profile add
add a bandw idth profile
32
option bw -profile del
delete a bandw idth profile
33
option traffic-selector
Traffic selector configuration
34
option traffic-selector add
add a traffic selector for option
35
option traffic-selector add ip
add a traffic selector for option
36
option traffic-selector add mac
add a traffic selector for option
37
option traffic-selector add port
add a traffic selector for option
38
option traffic-selector add vlan
add a traffic selector for option
39
option traffic-selector add dscp
add a traffic selector for option
40
option traffic-selector del
delete a traffic selector rule for option
11.2 qos lan trustmode cos enable <ltlanPort>
S.No
Command Name
Description

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
