D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
34
119
net tahi start-RA-AdvCurHopLimit(15)
start sending RA w ith
AdvCurHopLimit value as 15.
120
net tahi ipv6-dow n
disable the ipv6 stack on the router.
121
net tahi ipv6-up
enable the ipv6 stack on the router.
122
net tahi ipv6-global-up
enable the ipv6 stack on the router
and adds global ip.
123
net tahi ipv6-Alias-Add(LAN) <ltip6_address>
Add ipv6 address to LAN interface.
124
net tahi ipv6-Alias-Del(LAN) <ltip6_address>
Delete an ipv6 address from LAN
interface.
125
net tahi ipv6-Alias-Add(OPTION) <ltip6_address>
Add ipv6 address to OPTION
interface.
126
net tahi ipv6-Alias-Del(OPTION) <ltip6_address>
Delete an ipv6 address from OPTION
interface.
127
net tahi neigh-cache-del
deletes the ipv6 neighbor cache.
128
net tahi reachable-time <lttime>
set the reachable time of neighbour
cache entries
129
net tahi mcast-start
start ipv6 multicast
130
net tahi mcast-stop
stop ipv6 multicast
131
net tahi ping6 <ltip> <ltsize>
ping6 on LAN interface with count one
132
net tahi pmtu-route-add <ltipAdd>
add ipv6 route on lan interface.
133
net tahi disable-ipv6-firewall
disable ipv6 firew all.
134
net tahi show -LAN-ip
show ipv6 addresses of LAN
interface.
135
net upnp
Upnp configuration mode
136
net upnp configure
Upnp configuration mode
7.7 VPN configuration commands
The command vpn at the CLI prompt would give the description of all the configuration
commands in the branch vpn , which is as follows:
Sl No
Command Name
Purpose
1
vpn l2tp
vpn policy mode.
2
vpn l2tp server
vpn policy mode.
3
vpn l2tp server configure
l2tp server configuration mode
4
vpn pptp client
vpn policy mode.
5
vpn pptp client configure
pptp client configuration mode
6
vpn pptp client_action <ltaction>
vpn pptp client action set.
7
vpn pptp
vpn policy mode.
8
vpn pptp server
vpn policy mode.
9
vpn pptp server configure
pptp server configuration mode
10
vpn sslvpn
sslvpn configuration commands
11
vpn sslvpn portal-layouts
sslvpn portal layout configuration
commands
12
vpn sslvpn portal-layouts add
Add sslvpn portal layout
13
vpn sslvpn portal-layouts edit <ltrow_id>
Edit sslvpn portal layout
14
vpn sslvpn portal-layouts delete <ltrow_id>
Delete sslvpn portal layout
15
vpn sslvpn portal-layouts set-default <ltrow_id>
Set the portal as default
16
vpn sslvpn portforwarding
sslvpn portforwarding configuration
commands
17
vpn sslvpn portforwarding appconfig
sslvpn portforwarding application
configuration commands
18
vpn sslvpn portforwarding appconfig add
Add an application configuration rule
19
vpn sslvpn portforwarding appconfig delete <ltrow_id>
Delete an application configuration rule
20
vpn sslvpn portforwarding hostconfig
sslvpn portforwarding host

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
