Page #43 background image
Wireless Controller CLI Reference Guide
41
String
7
password
Configure the AP Authentication Passw ord.
String
8
profileid
Set the AP Profile ID to use for configuration.
AP Profile ID
9
ssid
Configure the stand-alone AP expected SSID
String
10
channel
Configure the stand-alone AP expected
channel
Unsigned integer
11
w ds_mode
Configure the stand-alone AP expected WDS
mode
stand-alone AP expected WDS mode.
12
security_mode
Configure the stand-alone AP expected
security mode
Stand Alone AP Security Mode
13
w ired-mode
Configure the stand-alone AP expected w ired
network mode.
stand-alone AP expected w ired network
mode
14
radio1-sentry
Configure fixed radio channel/pow er settings
15
radio2-802.11b/g/n
Configure fixed radio channel/pow er settings
16
radio1-sentry channel
Configure a fixed channel for the radio
Unsigned integer
17
radio1-sentry power
Configure a fixed transmit pow er for the
radio.
range of power perventage
18
radio2-802.11b/g/n
channel
Configure a fixed channel for the radio.
Unsigned integer
19
radio2-802.11b/g/n
power
Configure a fixed transmit pow er for the
radio.
range of power perventage
8.4 wlan ap_management ap_database delete
<macaddr>
S.No
Command Name
Description
Type and Description
1
<macaddr>
w lan ap-management ap-database delete an
mac-address
MAC address AA:BB:CC:DD:EE:FF
w here each part is in the range 00-FF
8.5 wlan ap_management rf_management
configure
S.No
Command Name
Description
Type and Description
1
save
Save rf management configuration changes.
2
cancel
Roll back configuration changes.
3
exit
Save rf management configuration changes
and current mode.
4
channel_plan
Configure the channel plan parameters.
5
power_plan
Configure the pow er plan parameters.
6
channel_plan plan
Specify radio frequency band
Radio frequency Band
7
channel_plan mode
Set the mode of channel plan assignment.
Channel Plan Mode
8
channel_plan
history_depth
Configure the number of the channel
algorithm iterations that WS remembers.
Unsigned integer
9
channel_plan interval
Configure the interval at w hich to compute
and apply channel adjustments.
Unsigned integer
10
channel_plan time
Configure the scheduled time at w hich to
compute and apply channel adjustments.
String
11
power_plan interval
Configure the interval at w hich to compute
