D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
59
9.15 system switch_settings jumbo_frame
configure
S.No
Command Name
Description
Type and Description
1
save
Save jumbo frame configuration changes.
2
exit
Save jumbo frame configuration changes and exit current
mode.
3
cancel
Roll back jumbo frame configuration changes.
4
jumbo_frame
Enable/Disable jumbo frame
Boolean choice
9.16 system time configure
S.No
Command Name
Description
Type and Description
1
save
Save time configuration changes.
2
exit
Save time configuration changes and current mode.
3
cancel
Roll back time configuration changes.
4
timezone
Timezone
Timezones
5
auto_daylight
Specify w hether system automatically adjusts for daylight
savings time
Boolean choice
6
configure_ntp_servers
Specify w hether to use ntpp servers or user will set date
and time
Boolean choice
7
use_default_servers
Specify w hether to use system default NTP servers.
Boolean choice
8
ntp_server1
Set NTP server#1.
String
9
ntp_server2
Set NTP server#2
String
10
ntp_year
Set year for the date
Year
11
ntp_month
Set month for the date
Month in the format MM(01-12)
12
ntp_day
Set Day for the date
Day in the format DD(01-31)
13
ntp_hour
Set hour for the date
HH(00-23) using 24 hour clock
14
ntp_minutes
Set minutes for the date
minute in the format MM(00-59)
15
ntp_seconds
Set seconds for the date
Second in the format SS(00-
59)
16
ntp_sync_interval
Set seconds for the date
Unsigned integer
9.17 system traffic_meter configure
S.No
Command Name
Description
Type and Description
1
save
Save traffic meter configuration changes.
2
exit
Save traffic meter configuration changes and exit current mode.
3
cancel
Roll back traffic meter configuration changes.
4
enable
Enable/Disable the traffic meter status
Boolean choice
5
limit_type
Set traffic Limit Type 0(No limit), 1(Dow nload only), 2(Both
Directions)
traffic meter types
6
monthly_limit
Set the monthly limit value of the traffic meter

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
