Page #96 background imageLoading...
Page #96 background image
Wireless Controller CLI Reference Guide
94
Enter No and give valid static dns addresses
125
japanese_pppoe
secondary_profile
primary_dns
Valid primary DNS Server IP Address
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
126
japanese_pppoe
secondary_profile
secondary_dns
Valid secondary DNS Server IP Address
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
127
japanese_pppoe
secondary_profile
get_ip_from_isp
Enter Yes to get IP dynamically from ISP if you have
not been assigned any static IP address. The ISP w ill
automatically assign an IP address to the router
using PPPOE network protocol. Otherwise Enter No
and give valid static IP address
Boolean choice
128
japanese_pppoe
secondary_profile
static_ip
Valid IP Address
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
129
japanese_pppoe
secondary_profile
subnet_mask
Valid subnet mask
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
130
japanese_pppoe
mac_type
Select the Mac Address Source
Types of mac address source
131
japanese_pppoe
mac_address
enter Valid MAC address
MAC address
AA:BB:CC:DD:EE:FF where each
part is in the range 00-FF
12.27 net Option mode configure
S.No
Command Name
Description
Type and Description
1
save
Save Option mode configuration changes.
2
cancel
Roll back ipv4 Option configuration changes.
3
exit
Save Option mode configuration changes and current
mode.
4
Option_mode_type
Select among the options: SINGLE_OPTION,
LOAD_BALANCING, AUTO_ROLLOVER
Types of OPTION modes
5
loadbalancing
If Mode Type selected is LOAD_BALANCING, this
field gives you options to configure
LOAD_BALANCING credentials
6
loadbalancing algo
Enter the type of LoadBalancing Algo
Types of Loadbalancing algorithms
7
loadbalancing
failover_method
Select the Fail Over detection method
8
loadbalancing spillover
Spill Over Configuration Parameters
9
loadbalancing spillover
load_tolerance
Percentage of max bandwidth after which the router
sw itches to secondary OPTION
Unsigned integer
10
loadbalancing spillover
max_bandw idth
Sets the maximum bandwidth tolerable by the
Primary OPTION.If the bandw idth goes below the
load tolerance value of configured Max Bandw idth,
the router sw itches to secondary OPTION.
Unsigned integer
11
loadbalancing
failover_method type
Select the Fail Over detection method
Types of Faillover Detection
methods
12
loadbalancing
failover_method dns
13
loadbalancing
failover_method dns
ipaddr_Option1
IP address AAA.BBB.CCC.DDD
w here each part is in the range 0-
255
