Wireless Controller CLI Reference Guide
55
48
syslog_server
server_name6 enable
Boolean Choice Y/N
Boolean choice
49
syslog_server
server_name6 name
Set Syslog server.
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
50
syslog_server
server_name6 severity
Set Syslog severity.
syslog server severity types
51
syslog_server
server_name6 facility
Set Syslog facility.
syslog server facility ID types
52
syslog_server
server_name7 enable
Boolean Choice Y/N
Boolean choice
53
syslog_server
server_name7 name
Set Syslog server.
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
54
syslog_server
server_name7 severity
Set Syslog severity.
syslog server severity types
55
syslog_server
server_name7 facility
Set Syslog facility.
syslog server facility ID types
56
syslog_server
server_name8 enable
Boolean Choice Y/N
Boolean choice
57
syslog_server
server_name8 name
Set Syslog server.
IP address
AAA.BBB.CCC.DDD w here
each part is in the range 0-255
58
syslog_server
server_name8 severity
Set Syslog severity.
syslog server severity types
59
syslog_server
server_name8 facility
Set Syslog facility.
syslog server facility ID types
9.4 system logging ipv6 configure
S.No
Command Name
Description
Type and Description
1
save
Save ipv6 logging configuration changes.
2
exit
Save ipv6 logging configuration changes and exit current
mode.
3
cancel
Roll back ipv6 logging configuration changes.
4
lan_Option_accept_en
able
Enable/Disable logging for the LAN to Option Accept
packets
Boolean choice
5
lan_Option_drop_enabl
e
Enable/Disable logging for the LAN to option Dropped
packets
Boolean choice
6
Option_lan_accept_en
able
Enable/Disable logging for the option to LAN Accept
packets
Boolean choice
7
Option_lan_drop_enabl
e
Enable/Disable logging for the Option to LAN Dropped
packets
Boolean choice
9.5 system remote_management https
configure
S.No
Command Name
Description
Type and Description
1
save
save access Management changes for https.
2
exit
Save access Management changes for https and exit
current mode.
3
cancel
Roll back Remote Mgmt changes.
4
enable
Enable/disable remote mgmt over https.
Boolean choice
