D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
105
12.45 net routing dynamic configure
S.No
Command Name
Description
Type and Description
1
save
Save dynamic route changes.
2
exit
Save dynamic routes changes and exit
current mode.
3
cancel
Roll back rip configuration changes.
4
direction
rip direction None, In only, Out only,
Both.
rip direction
5
version
Rip version
rip version
6
authentication_enable
Enable/Disable Authentication for RIP-
2B/2M
Boolean choice
7
first_key
first MD5 key
8
first_key id_number
First MD5 Key Id
Unsigned integer
9
first_key authentication_id
First MD5 Authentication Key
String
10
first_key valid_from
First MD5 Key Not Valid Before
entered date
11
first_key valid_from month
month in w hich md5 authentication key
validity starts
Month in the format MM(01-12)
12
first_key valid_from day
day in which md5 authentication key
validity starts
Day in the format DD(01-31)
13
first_key valid_from year
year in which md5 authentication key
validity starts
Year
14
first_key valid_from hour
hour in w hich md5 authentication key
validity starts
HH(00-23) using 24 hour clock
15
first_key valid_from minute
minute in which md5 authentication
key validity starts
minute in the format MM(00-59)
16
first_key valid_from second
second in w hich md5 authentication
key validity starts
Second in the format SS(00-59)
17
first_key valid_to
First MD5 Key is Not Valid After
entered date
18
first_key valid_to month
month in w hich md5 authentication key
validity ends
Month in the format MM(01-12)
19
first_key valid_to day
day in which md5 authentication key
validity ends
Day in the format DD(01-31)
20
first_key valid_to year
year in which md5 authentication key
validity ends
Year
21
first_key valid_to hour
hour in w hich md5 authentication key
validity ends
HH(00-23) using 24 hour clock
22
first_key valid_to minute
minute in which md5 authentication
key validity ends
minute in the format MM(00-59)
23
first_key valid_to second
second in w hich md5 authentication
key validity ends
Second in the format SS(00-59)
24
second_key
Second MD5 Key Parameters
25
second_key id_number
Second MD5 Key Id
Unsigned integer
26
second_key authentication_id
Second MD5 Authentication Key
String
27
second_key valid_from
Second MD5 Key Not Valid Before
Entered date
28
second_key valid_to
Second MD5 Key Not Valid After
entered date
29
second_key valid_from month
month in w hich md5 authentication key
validity starts
Month in the format MM(01-12)
30
second_key valid_from day
day in which md5 authentication key
validity starts
Day in the format DD(01-31)

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
