D-Link DWC-1000 Reference Guide

Wireless Controller CLI Reference Guide
30
3
qos lan trustmode
trustmode configuration in the sw itch
4
qos lan trustmode cos
Configure cos based QoS on lan
5
qos lan trustmode dscp
Configure dscp based QoS on lan
6
qos lan cos-to-dscp-remarking
enable cos-to-dscp-remarking
7
qos lan queue
queue sheduling and management
configuration
8
qos lan cos-map
configures the cos-map for the
sw itch port
9
qos lan dscp-map
configures the cos-map for the
sw itch port
10
qos lan queue management
lan queue managenet configuation
11
qos lan queue scheduling-algo
lan queue scheduling algorithm
configuration
12
qos lan status
Display status of lan QoS
13
qos lan enable
enable QoS on LAN
14
qos lan disable
disable QoS on LAN
15
qos lan trustmode show
show the trustmode on the sw itch
16
qos lan trustmode cos enable <ltlanPort>
configures CoS LAN, QoS has to be
enabled first.
17
qos lan trustmode dscp enable <ltlanPor t>
configures DSCP on LAN, QoS has
to be enabled first.
18
qos lan cos-map configure <ltcosValue>
<ltpriorityQueue>
configure cos map for qos
19
qos lan cos-map show
show the cos-map for qos
20
qos lan dscp-map show
display dscp priority mappin on
sw itch
21
qos lan dscp-map configure <ltdscpValue>
<ltpriorityQueue>
Configure DSCP map for qos
22
qos lan cos-to-dscp-remarking enable
enables cos-to-dscp remarking
23
qos lan cos-to-dscp-remarking disable
disables cos-to-dscp remarking
24
qos lan cos-to-dscp-remarking status
Display status of cos-to-dscp-
remarking
25
qos lan cos-to-dscp-remarking configure <ltcosValue>
<ltdscpValue>
configures cos-to-dscp remarking
26
qos option status
Display QoS status on OPTION
27
qos option enable
Enable QoS on option interface
28
qos option disable
Disable QoS on option interface
29
qos option bandw idth set <ltwanInterface>
<ltupStreamBW> <ltdownStreamBW>
set the bandwidth for optional option
30
qos option bandw idth
configure bandwidth for option
interface
31
qos option traffic-selector
configure traffic selector
configuration
32
qos option traffic-selector add
configure traffic selector
configuration
33
qos option bandw idth profile
configure bandwidth profiles for
option interface
34
qos option bandw idth show <ltwanInterface>
Display bandwidth setting for
dedicated option
35
qos option bandw idth profile add <ltwanInterface>
<ltbwProfileName> <ltpriority> <ltmaxBW> <ltminBW>
add a bw -profile for option
36
qos option bandw idth profile del <ltbwProfileName>
delete a bw -profile on option
37
qos option bandw idth profile show
display all the bandw idth profiles that
are configured
38
qos option traffic-selector show
show s the traffic selectors for the
option interface
39
qos option traffic-selector add ip <ltipAddress>
<ltser vice> <ltbwProfile>
add a traffic selector for option
40
qos option traffic-selector add mac <ltmacAddress>
add a traffic selector for option

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
