Figure 5-120
Please refer to the following sheet for detailed information.
This function is disabled by default. Check the box here to enable
this function so that you can control the zero-channel encoding
function at the WEB.
System default setup is H.264. You can set according to device
capability.
The resolution value may vary due to different device capabilities.
Please select from the dropdown list.
The frame rate value may vary due to different device capabilities.
Please select from the dropdown list.
The default setup is 1024Kb/S. The bit rate value may vary due to
different device capabilities and frame rate setups. Please select
from the dropdown list.
5.5.5.3 Video Matrix
From main menu->Setup->System->Video matrix, the interface is shown as in Figure 5-121.
Here you can set video output channel and interval.
Figure 5-121
Please refer to the following sheet for detailed information.
Check the box here to enable this function.
It is to set the interval from current channel group to the next
channel group.
Please select from the dropdown list. Please note the different
series products support different window split mode.
Select a channel group and then click to delete it.
