ED 15062-7 • MICROTECH II CHILLER CONTROLLER 102 www.DaikinApplied.com
aPPendIx a
aPPendIx a
Protocol Implementation Conformance Statement (PICS)
This section contains the Protocol Implementation
Conformance Statement (PICS) for the MicroTech II Chiller
Unit Controller of Daikin Applied as required by ANSI/ASHRAE
Standard 135-2004, BACnet: A Data Communication Protocol
for Building Automation and Control Networks.
BACnet Protocol Implementation
Conformance Statement
Date: June 2015
Vendor Name: Daikin Applied
Product Name: MicroTech II Chiller Unit Controller
Product Model Number: MTII Chiller UC
Applications Software Version: 2.00
Firmware Revision: AmBCM-10 - BmBCM-485-15E
BACnet Protocol Revision: Version 1
Revision 4
Product Description
The MicroTech II Chiller Unit Controller with optional BACnet
Communication Module is a microprocessor-based controller
designed to operate Daikin Applied chillers and be integrated
into BACnet building automation systems.
BACnet Standardized Device Prole
 BACnet Operator Workstation (B-OWS)
 BACnet Building Controller (B-BC)
 BACnet Advanced Application Specic Controller (B-AAC)
 BACnet Application Specic Controller (B-ASC)
 BACnet Smart Sensor (B-SS)
 BACnet Smart Actuator (B-SA)
BACnet Interoperability Building Blocks
(BIBBs) Supported
BIBB Name Designation
Data Sharing – ReadProperty – B DS-RP-B
Data Sharing – ReadPropertyMultiple – B DS-RPM-B
Data Sharing – WriteProperty – B DS-WP-B
Data Sharing – WritePropertyMultiple – B DS-WPM-B
Alarm and Event – Notication Internal – B AE-N-I-B
Alarm and Event – ACK – B AE-ACK-B
Alarm and Event – Information – B AE-INFO-B
Device Management – Dynamic Device Binding – B DM-DDB-B
Device Management – Dynamic Object Binding – B DM-DOB-B
Device Management – DeviceCommunicationControl – B DM-DCC-B
Device Management – TimeSynchronization – B DM-TS-B
Device Management – UTCTimeSynchronization – B DM-UTC-B
Device Management – ReinitializeDevice – B DM-RD-B
Device Management – Restart – B DM-R-B
Standard Object Types Supported
Object-Type Dynamically Creatable Dynamically Deleteable Optional Properties Supported Writable Properties not Required to be Writable Proprietary Properties
Analog Input
□ □
Description
Reliability
Read_Only
1
Analog Output
□ □
Description
Reliability
Relinquish
Default
Read_Only
1
Binary Input
□ □
Description
Reliability
Inactive_Text
Active_Text
Read_Only
1
Binary Value
□ □
Description
Reliability
Inactive_Text
Active_Text
Priority Array
Relinquish Default
Prole_Name
Present
Value
Relinquish
Default
Read_Only
1
Device
□ □
Description
Location
Local_Time
Local_Date
UTC_Offset
Daylight_Savings_
Status
Max_Master
Max_Info_Frames
Location
Multi-state
Input
□ □
Description
Reliability
State_Text
Read_Only
1
Multi-state
Output
□ □
Description
Reliability
State_Text
Relinquish
Default
Read_Only
1
1. Read_Ony is a read only proprietary property used to indicate whether the
Present_Value is read-only (0), writeable but not commandable (1) or writeable
and commandable (2).
