deTaIled daTa PoInT InformaTIon
www.DaikinApplied.com 25 ED 15062-7 • MICROTECH II CHILLER CONTROLLER
Capacity Limit Output
Keypad Menu Path:
No Keypad Equivalent
This output variable is a measure of the ratio of operating capacity to full capacity expressed in percent.
This output variable indicates the current value of the Capacity Limit. (A42)
Measurement Units Data Type Valid Range Default Value
Percent of maximum capacity NA
BACnet: Real
LONWORKS: Fixed-Point
Scalar signed long
0% to 160%. See Below
BACnet
Variable Details
Object Identier Property Identier
Object Type Type Enumeration Instance Property Name Property Enumeration
Analog Input 0 8 Present Value 85
Object Name
ActiveCapacityLimit
LONWORKS
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size SCPT_Reference SCPT Index
nvoCapacityLim
(output)
Chiller lev_percent 81 two bytes NA NA
Capacity Limit Setpoint
Keypad Menu Path:
No Keypad Equivalent
Capacity Limit is a measure of the ratio of operating capacity to full capacity expressed in percent. This
level may be adjusted via an operator workstation or other network device, but cannot be adjusted
above a factory-specied limit. The input network variable sets the operating value (input). Refer to the
appropriate Operation Manual for suitable variable values. (A3)
Measurement Units Data Type Valid Range Default Value
Percent of maximum capacity NA
BACnet: Real
LONWORKS: Fixed-Point
Scalar signed long
0% to 160%. See Below
BACnet
This read or read/write property sets the maximum capacity limit of the chiller. This level may be adjusted, but cannot be adjusted
above a factory-specied limit.
Variable Details
Object Identier Property Identier
Object Type Type Enumeration Instance Property Name Property Enumeration
Analog Output 1 32 Present Value 85
Object Name
NetworkCapacityLimitPct
Default Value (Relinquish_Default)
100%
LONWORKS
Input (nvi) The input network variable sets the maximum capacity level of the chiller. This level may be adjusted via an operator
workstation or other network device, but cannot be adjusted above a factory-specied limit.
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size SCPT_Reference SCPT Index
nviCapacityLim
(input)
Chiller lev_percent 81 two bytes NA NA
