ED 15062-7 • MICROTECH II CHILLER CONTROLLER 58 www.DaikinApplied.com
deTaIled daTa PoInT InformaTIon
Cool Setpoint
Keypad Menu Path:
Menu
\Set
\Unit SPs (3)
The Cool Setpoint data point determines the temperature of the Leaving Chilled Water. LONWORKS
network variables set operating Temperature. The BACnet property is a commandable property of a
Analog Output object. Refer to the appropriate Operation Manual for suitable variable values. (A47)
Measurement Units Data Type Valid Range Default Value
Temperature
BACnet: °F
LONWORKS: °C
BACnet: Real
LONWORKS: Fixed Point
Scalar signed long
Dependent on
Chiller mode and model
See below
BACnet
This commandable property sets the temperature of the Leaving Chilled Water. This level may be adjusted via an operator
workstation or other network device.
Variable Details
Object Identier Property Identier
Object Type Type Enumeration Instance Property Name Property Enumeration
Analog Output 1 29 Present Value 85
Object Name
NetworkCoolTempSetpoint
Default Value (Relinquish_Default) 44°F
LONWORKS
This input network variable provides the Cooling setpoint of the Leaving Chilled Water when the chiller is operating in the Cooling
Mode. The Cooling mode is the normal mode of chiller operation, unless overridden by using the optional Mode variable to change
to another mode.
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size SCPT_Reference SCPT Index
nviCoolSetpt Chiller temp_p 105 two bytes NA NA
Cool Setpoint
Keypad Menu Path:
No Keypad Equivalent
This conguration network parameter establishes the default Setpoint for the Leaving Chilled Water
Temperature unless nciDefaults=1 (see Default Values on page 59). When nciDefaults=1, use the
values specied during manufacturing. Refer to the appropriate Operation Manual for suitable variable
values.
Measurement Units Data Type Valid Range Default Value
Temperature LONWORKS: °C
LONWORKS: Fixed Point
Scalar signed long
LONWORKS: -12.2–48.8°C See Below
LONWORKS
Default Value 7.2°C
The chiller object uses the conguration value of nciCoolsetpt on power-up or loss of communication unless the conguration
parameter nciDefaults =1 (See Default Values on page 59) unless overridden by using the optional Mode variable to change to
another mode.
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size SCPT_Reference SCPT Index
nciCoolSetpt Chiller temp_p 105 two bytes SCPT_CoolSetpoint 75
