deTaIled daTa PoInT InformaTIon
www.DaikinApplied.com 21 ED 15062-7 • MICROTECH II CHILLER CONTROLLER
deTaIled daTa PoInT InformaTIon
This section lists the information (i.e. data) that is available to
the BAS via BACnet or LONWORKS communication protocols.
This information is used to safely operate and log the
performance of the chiller. The systems integrator also uses
this information when creating custom graphics.
NOTE: Data points are referred to as “properties” in
the BACnet protocol and “network variables” or
“conguration parameters” in the LONWORKS
protocol. In this document, the text refers to this
information as a “data point.” In general, the data
point is applicable to both BACnet and LONWORKS.
When a data point is specic to the BACnet protocol,
the text refers to a “property.” When a data point is
specic to the LONWORKS protocol, the text refers to
a “network variable” or “conguration parameter.”
Table 2: Data Points for Chiller Models
Data Point
WSC, WDC,
WPV, HSC, HDC,
TSC, WMC, WCC
AGZ ACZ AGS WGZ, TGZ WGS
Active Setpoint X X X X X
Actual Capacity X X X X X
Actual RPM X*****
Capacity Limit (LONWORKS Conguration) X X* X* X X X
Capacity Limit Output X X* X* X X X
Capacity Limit Setpoint X X* X* X X X
Cavity Temperature X*****
Chiller Enable X X X X X X
Chiller Enable (LONWORKS Conguration) X X X X X X
Chiller Limited X X* X* X X X
Chiller Local/Remote X X X X X X
Chiller Location X X X X X X
Chiller Mode (LONWORKS Conguration) X X X X X
Chiller Mode Output X X X X X
Chiller Mode Setpoint X X X X X
Chiller ON OFF X X X X X X
Chiller Status BACnet X X X X X X
Chiller Status (LONWORKS) X X X X X X
Chiller Type X X X X X
Compressor Current** X X
Compressor Discharge Temperature X X X
Compressor Percent RLA X X
Compressor Power** X X
Compressor Run Hours X X X X X X
Compressor Select X X X X X X
Compressor Starts X X X X X X
Compressor Status X*****
Compressor Suction Line Temperature X X X X
Compressor Voltage** X X
Condenser Entering Water Temperature X X X
Condenser Flow Switch Status X X X
Condenser Leaving Water Temperature X X X
Condenser Pump Run Hours X
Condenser Refrigerant Pressure X X X X X X
Condenser Saturated Refrigerant
Temperature
X X X X X X
Condenser Water Flow Rate X X
Condenser Water Pump Status X X X
Cool Setpoint X X X X X
Cool Setpoint (LONWORKS Conguration) X X X X X
Current Alarm X X X X X X
*Dual Circuit Only
**Optional Solid State Starter Required. Voltage, Power and Current are per compressor
***Not available on the WMC
****AGS A and B vintage only
*****WMC only
