Daikin MicroTech II Installation And Maintenance Manual

ED 15062-7 • MICROTECH II CHILLER CONTROLLER 32 www.DaikinApplied.com
deTaIled daTa PoInT InformaTIon
Chiller ON OFF
Keypad Menu Path:
Menu
\View
\Unit
\Status
This output network variable indicates the current state of the chiller. The OFF state is represented by
state = FALSE and value = 0. The other discrete states are represented by state = TRUE and value > 0.
It is normally recommended to monitor the “Chiller Status” data point for the current operating state of
the chiller. (D2)
Measurement Units Data Type Valid Range Default Value
Chiller State NA LONWORKS: structure See Below NA
LONWORKS
The LONWORKS equivalent of this data point is part of the Chiller Status network variable output (see page 33).
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size
nvoOnOff Chiller switch 06 two bytes
Chiller Power
Keypad Menu Path:
No Keypad Equivalent
This variable indicates the totalized compressor kilowatts. (I116).
Measurement Units Data Type Valid Range Default Value
Percent of chiller capacity NA
BACnet: Real
LONWORKS: Fixed-Point
Scalar signed long
0–160% NA
BACnet
Variable Details
Object Identier Property Identier
Object Type Type Enumeration Instance Property Name Property Enumeration
Analog Input 0 67 Present Value 85
Object Name
TotalChillerKW
LONWORKS
No LONWORKS equivalent.
